Load in push: 1000N
Load in pull: 0N
Color: Black
IP grade: IP20
Stroke length: 342±2mm、348±2mm
Installation dimensions: L=497±2mm（S=348±2mm）、L=486±2mm（S=342±2mm）
Noise level: ≤40dB(Semi-anechoic chamber, 500mm test distance)
Safety nut: None
Double Hall sensor : None
Only push no pull option : None
Built-in electrical limit switch
Weight: About 1.99kg (different stroke length and installation dimensions with different weight )
Static bending moment: lateral load are not allowed
Load in push: 1000N
Load in pull: 0N
Color: Black
IP grade: IP20
Stroke length: 342±2mm、348±2mm
Installation dimensions: L=497±2mm（S=348±2mm）、L=486±2mm（S=342±2mm）
Noise level: ≤40dB(Semi-anechoic chamber, 500mm test distance)
Safety nut: None
Double Hall sensor : None
Only push no pull option : None
Built-in electrical limit switch
Weight: About 1.99kg (different stroke length and installation dimensions with different weight )
Static bending moment: lateral load are not allowed
