Load in push: 6000N，4000N，3000N，2000N，1500N
Color: Grey / Black
IP grade: IP54
Stroke length:
6000N: 50-200mm(in steps of 4mm)
4000N: 50-300mm(in steps of 4mm)
3000N: 50-300mm(in steps of 4mm)
2000N：50-400mm（in steps of 4mm）
1500N：50-400mm（in steps of 4mm）
Installation dimensions:
L=S+170（0＜S≤300）
L=S+180（300＜S≤400)
Noise level≤48dB(environmental noise≤40dB)
Safety nut: optional
Hall sensor : optional
Only push : optional
Built-in electrical limit switch
Weight: About 1.5kg (different stroke length and installation dimensions with different weight)
Static bending moment: lateral load is not allowed
