Linear Actuator JC35L18

Load in push: 8000N、6000N、5000N、4000N、3000N

Color: Gray

IP grade:  Max. IPX6W

Stroke length:
Standard:

8000N：50-500mm

6000N：50-500mm

Fast version：

6000N：50-300mm

5000N：50-300mm

4000N：50-800mm

3000N：50-300mm

Installation dimensions:

Standard:

L=S+175（50≤S≤400）

L=S+195（400＜S≤500）
Fast version:

L=S+175（50＜S≤200）

L=S+185（200＜S≤800）

Noise level: ≤48dB, (4000N, Spindle pitch=7.5mm version ≤52dB) ( environmental noise≤40dB)

Safety nut: optional

Hall sensor : optional

Only push no pull option : optional

Built-in electrical limit switch.

Weight: About 3kg (different stroke length and installation dimensions with different weight )

Static bending moment: lateral load are not allowed.
