Linear Actuator JC35B5-QH

Load in push：3000N，2000N

Color:Gray/Black

IP grade: IPX4

Stroke length:

3000N：50-400mm（in steps of 4mm）

2000N：50-400mm（in steps of 4mm）

Installation dimensions:

L=S+177（50＜S≤400）

L=283

Noise level: ≤45dB, ( environmental noise≤40dB)

Safety nut: optional

Hall sensor : optional

Reed switch: optional

Small signal function (match with JIECANG control box): optional

Built-in electrical limit switch.

Weight: About 2.3kg (different stroke length and installation dimensions with different weight )

Static bending moment: lateral load are not allowed.
